FM582
DESCRIPTION
ONWAY WME Carbon Full-Suspension MTB Frame
Built for Demanding All-Mountain Riding
The CONWAY WME is a carbon fiber full-suspension mountain bike frame designed for Trail, All-Mountain, and Enduro riding. It is suited to riders looking for a versatile platform for technical trails, challenging descents, and varied off-road terrain.
Featuring a Horst Link four-bar rear suspension design, a 65° head angle, and modern component standards, the WME provides a foundation for a capable all-mountain build.
The frame uses 12×148 mm BOOST rear spacing and a BB89/92 press-fit bottom bracket interface. Compatibility with 27.5" and 29" wheel configurations provides flexibility when selecting wheels and tires for the intended build.
FEATURES
Carbon Fiber Frame Built around a carbon fiber frame platform designed for demanding all-mountain riding, balancing weight considerations with the structural performance required for varied terrain.
Horst Link Four-Bar Rear Suspension The Horst Link rear suspension design works with the rear shock to help the rear wheel track uneven terrain and absorb trail impacts.
65° Head Angle The 65° head angle is designed for modern all-mountain and enduro riding, supporting control and stability on steep descents and technical trails.
BOOST 148 Rear Spacing Features a 12×148 mm BOOST rear axle standard for compatible rear hubs and thru-axles.
150–170 mm Fork Travel Recommended fork travel is 150–170 mm, with a specified axle-to-crown (A2C) length of 566–586 mm. Verify fork compatibility before assembly.
230×65 mm Rear Shock Designed for a 230×65 mm rear shock, with mounting hardware specifications listed as 10×31 mm / 8×25 mm. Confirm the exact mounting dimensions and hardware before ordering.
27.5" / 29" Wheel Compatibility Supports compatible 27.5" and 29" wheel configurations, with a specified maximum tire size of 29×2.5". Actual clearance depends on tire dimensions, rim width, and frame size.
Included Frame Accessories Includes a seatpost clamp, rear thru-axle, chain guide, and complete ZS44/56 headset set, as specified.
Four Frame Sizes Available in S, M, L, and XL to accommodate different rider heights and fit preferences.
Specifications
Brand / Model
CONWAY WME
Product Type
Carbon Full-Suspension MTB Frame
Intended Use
Trail / All-Mountain / Enduro
Frame Material
Carbon Fiber
Rear Suspension Design
Horst Link Four-Bar
Available Sizes
S / M / L / XL
S Seat Tube Length
400 mm
M Seat Tube Length
430 mm
L Seat Tube Length
460 mm
XL Seat Tube Length
500 mm
Recommended Rider Height
S: 160–170 cm; M: 170–178 cm; L: 178–186 cm; XL: 186–195 cm
Head Angle
65°
Rear Axle Standard
12×148 mm BOOST
Bottom Bracket
BB89/92 Press-Fit
Recommended Fork Travel
150–170 mm
Fork Axle-to-Crown Length
566–586 mm
Rear Shock Size
230×65 mm
Shock Mounting Hardware
10×31 mm / 8×25 mm
Wheel Compatibility
27.5" / 29"
Maximum Specified Tire Size
29×2.5"
Disc Rotor Compatibility
180 mm
Seatpost Diameter
31.6 mm
Approx. Frame Weight
2,800 g
