TZA315
DESCRIPTION
This snow bike front fork is equipped with a brake line fixing buckle, and the dropout is equipped with a 15*135 mm size, with unique 120 mm travel scale size line.
FEATURES
Can be assembled snow dune buggy
Lock system supports manual lock/remote lock system.
Magnesium alloy air suspension front, suitable for electric bicycles.
Brake line fixing buckle Fix the brake line to make the brake line smooth and beautiful, making cycling more comfortable and tidy.
Compatible brake disc suitable for 160mm, 180mm or 203mm.
Specifications
Type de fourche
fourche à air comprimé 20*4.0 pouces
Diamètre du tube
32mm
Matériau
Alliage d'aluminium
Voyage exposé
120mm
Déplacement mobile
100mm
Convient pour roue
20pouces
Largeur maximale du pneu
4.0 pouces
Taille du tube de direction
Tube droit 28.6mm
Taille de l'essieu
9x135mm
Valeur maximale de pression d'air
Environ 120PSI
Couleur
noir
Poids
2100g(± 50g)
Service
We provide PDF documents for installation instructions for various products.
You can check out our installation and maintenance videos for FrontFork.123
TZA315
2024-2025 Catalog
Learn how to quickly set sag, air spring pressure, compression adjustments, rebound adjust, additional tuning options and more.
The recommended settings in this tuning guide are designed to be a starting point, in order to get you out on your first ride in as few steps as possible.
