SNA484
DESCRIPTION
Adjustable travel and damping, 150mm of travel, and supports damping adjustment, allowing for a fine-tuned ride experience to suit individual needs; upgraded air pressure performance, supporting up to 120 PSI of air pressure, provides custom suspension performance.
FEATURES
Reliable locking system-Manual operation function, capable of efficiently handling flat roads and steep hill climbs.
Adjustable damping-Equipped with damping adjustment function, it can be finely adjusted according to personal needs to enhance the riding experience.
Broad compatibility-Suitable for 26-inch, 27.5-inch, and 29-inch wheel diameters, and compatible with tires up to 2.4 inches wide.
Durable and lightweight design-The upper part is made of aluminum alloy, and the lower part is made of magnesium alloy, optimizing the balance between strength and weight.
Specifications
Model name
Aluminum and Magnesium Double-shoulder Air Fork
Inner tube diameter
32mm
Locking system
Shoulder-controlled
Travel
150mm
Color
Black
Weight
27.5:2350g; 29:2450g
Suitable wheels
26 inches/27.5 inches/29 inches
Maximum tire width
2.4 inches
Steerer tube size
Straight tube 28.6mm
Material
Aluminum alloy for upper tube, Magnesium alloy for fork legs
Damping adjustment
Supported
Bushing
Teflon Sponge
Axle size
9*100mm (quick release)
Maximum air pressure value
Approximately 120PSi
Compatible with brake discs
Default is 160mm, 180mm or 203mm requires the use of adapters
