SNA277
DESCRIPTION
This snowy beach bike with a fat front fork tire, magnesium alloy shock air fork 9*135mm, is suitable for quick-release wheel groups which can prevent screws from loosening and ensure more secure installation, with an arch bridge mudguard clearance, 74mm A-pillar disc brake seat, suitable for all disc brakes.
FEATURES
Maximum air pressure can reach 120 PSl, allow-ing riders to adjust the air suspension according to their weight and riding conditions for anoptimized experience.
Easily switch between locked and unlocked modes forefficient riding on flat or uphill terrains.
Exceptional TractionCold-Resistant Materials
Lightweight Design lHigh-strength durablemagnesium alloy Absorbs bumps for asmooth ride
The classic black and silver colorscheme is both aestheticallypleasing and practical,enhancingthe overall look of the bike.
Specifications
Fork type
20*4.0inch Compressed Air Fork
Tube diameter
32mm
Material
Aluminum Aly
Locking system
Manual Locking/Remote Locking
Exposed travel
120mm
Travel
100mm
For wheel size
20inch
Weight
2100g (± 50g)
Max tire width
4.0inch
Steering tube size
28.6mm straight tube
Distance size
9x135mm (quick release tire)
Max air pressure value
ximately 120PSI
Compatible with brake disc
160mm180mm or 203mm, an adapter is required by default
Color
Black
Service
We provide PDF documents for installation instructions for various products.
You can check out our installation and maintenance videos for FrontFork.123
SNA277
2024-2025 Catalog
Learn how to quickly set sag, air spring pressure, compression adjustments, rebound adjust, additional tuning options and more.
The recommended settings in this tuning guide are designed to be a starting point, in order to get you out on your first ride in as few steps as possible.
