OD469
DESCRIPTION
This oil disc is a four-piston hydraulic disc, with a braking force of 641N, precision CNC machining, and lightweight and durable 6061 aluminum alloy material, designed for stability and durability on any terrain.
FEATURES
Dual circuit oil flow with multiple pressure relief points ensures consistent performance and superior cooling.
Crafted from aerospace grade 6061 aluminum alloy combining strength and lightweight design.
Integrated CNC machining, manufactured for stability and durability in any terrain.
Brake lever adjustment screw, which can change the point of the brake lever, thereby affecting the response speed and power of the braking system.
Specifications
Model
SPEEDONE Soldier-2
Caliper type
Four-piston
Material
6061 Aluminum alloy
Braking force
641N
Brake line length
850mm / 1600mm
Disc diameter
160mm - 220mm
Disc thickness
1.7 - 2.3mm
Brake fluid type
SGS or above standard mineral oil
Brake pad type
Heat dissipation brake pad
Color:
Black, Titanium color, Purple
Weight
Front 250g / Rear 270g
Features
One-piece CNC milled caliper, double circulation oil circuit multi-point oil pressure release system, ensuring long-term stability.
