HU344
DESCRIPTION
This drum is suitable for all mountain bikes. The solid part is made of high-strength aluminum alloy material, which is strong and durable, oxidation-resistant impact-resistant, and does not deform. It can operate at high speed for a long time with overload. It is smoother, more wear-resistant, and quieter. The body uses an anodized coloring process that can well protect the metal surface. The outer circle is milled by Bohan car, and the spoke hole is accurately positioned and lightweight, which makes the car better riding experience.
FEATURES
Mountain bike freewheel hub, supports 8-12 speeds.
AL6061 full aluminum alloy hub body, built-in 903 bearings.
Standard 44mm six-bolt mounting hole, 32 holes on both sides of the flange.
High-quality carbon axle, CNC cutting process, chromium-molybdenum steel hub.
Specifications
Product Name
607R Hub
Material
Main body aluminum alloy drum/Chromium-molybdenum steel tower base/Carbon steel axle
Tower base
HG tower base/Supports 8-12 speeds
Number of spoke holes
32 holes
Opening size
Front hub 100mm/Rear hub 135mm
Axle size
53mm
Axle diameter
9.5mm
Bearing structure
Front double bearings/Rear double bearings
Weight
Front hub 364g/Rear hub 551g
Color
Black
Service
We provide PDF documents for installation instructions for various products.
You can check out our installation and maintenance videos for FrontFork.123
