FM499
DESCRIPTION
This frame continues the classic BSA threaded axle, with a tight bite and zero looseness! It has a high-strength ride that stablymits power, without any noise or vibration, and provides a solid backing for every sprint with a reliable structure. It is also compatible with 2.2-inch wide tires, the contact area of the tire surface by 15%, allowing you to control your ride freely in all terrains.
FEATURES
2000g ultra-light 6061 aluminum alloy frame, which increases the feeling of suspension and hovering by 30%, and as steady as a rock!
Beautiful welds, strong structure, uniform force and reliable process, which can enhance the strength of the welding part, reduce the risk of and improve the ability to resist impact and deformation.
Seat tube reinforcement to enhance impact resistance and effectively prevent cracking in the stressed parts, suitable for jumping and cycling professional
The enlarged conical head tube can match more high-performance front forks, so you can rest assured of compatibility
Specifications
Frame type
SPEEDONE Dirt Jump Frame
Wheel size
26 inches
material
6061 Aluminum Alloy
Head tube type
Conical 44-55mm
Top tube length
315mm
Rear wheel specification
10x135mm quick release
Bottom bracket specification
BSA threaded bottom bracket 73mm
Cable routing
External routing
Brake mounting type
51mm B post
Tire width support
22 inches
Seat post diameter
31.6mm
Frame weight
2000g
Recommended front travel
80mm~120mm
Service
We provide PDF documents for installation instructions for various products.
You can check out our installation and maintenance videos for FrontFork.123
FM499
2024-2025 Catalog
Learn how to quickly set sag, air spring pressure, compression adjustments, rebound adjust, additional tuning options and more.
The recommended settings in this tuning guide are designed to be a starting point, in order to get you out on your first ride in as few steps as possible.
