FM470
DESCRIPTION
This is a mountain bike soft tail frame, compatible with a variety of wheel sizes, made of high-strength aluminum alloy material, and is a multi-link suspension design that can reduce energy loss, provide enhanced pedaling efficiency and damping performance, allowing riders to sit steadily on rugged terrain to reduce fatigue and extend the time of riding.
FEATURES
The superior performance of full-ball bearings effectively reduces rotational friction.
8 bearings interlocking design, steel bearings, smooth and obstacle-free.
The stem angle of 65° head tube design provides better control when going downhill.
Semi-internal routing design maintains the design's simplicity, reduces wear, ensures easy maintenance,
BOOST rear axle, improves rigidity and is compatible with modern components Threaded bottom bracket more reliable.
Specifications
Model
Ambassador2
Material
6061 Aluminum Alloy
Rear Shock
ROCKSHOX Monarch
Rear Shock Type
Air Shock
Rear Shock Travel
200*57mm
Seatpost Size Compatible
31.6mm
Maximum Rear Wheel Travel
159mm
Head Tube Angle
65°
Wheel Compatibility
27.5 inches/29 inches
Brake Mount Type
Direct Mount
Suspension Design
4 Link
Bottom Bracket Specifications
Threaded 73mm
Rear Axle Standard
148*12mm BOOST
Internal Routing
Semi-Internal Routing
Head Tube Specifications
44/56mm (1/8 inch to 1/2 inch)
Weight
3500 grams (frame) 303 grams (rear shock)
Color
Black/Green/White/Gray
Service
We provide PDF documents for installation instructions for various products.
You can check out our installation and maintenance videos for FrontFork.123
